Suspensions module Easy Lift 4.0

352,46368,85 Ex. VAT

The Easy Lift 4.0 Suspensions module allows to take advantage of the potential of the car’s original pneumatic suspension system at the best. Its installation, totally plug and play, takes only 45 minutes at least; with no need to modify your car’s mechanics, with a simple click on Easy Lift’s controller or on the App available for Android and iOS devices, you can change the trim and height from ground at your own pleasure, depending on the ground conditions or presence of obstacles to face and exceed, independently from the vehicle’s speed.

7 variations of height from: -35mm to +75mm and Special programsWheel alignment, Extra Low and Recovery.

See all features on www.easylift-eas.com website

Description

The Standard programs allow 7 height variations, with factory configuration: -30mm-20mm-10mmNeutro;+35mm+55mm and +70mm.

By the Settings page of our App you’ll can change it and configure each preset in a measuring range from -35 to +75 millimeters in 5mm steps.

Easy Lift module can be used in addition to the Land Rover heights, in order to increase the range of combinations and variations reachable. Thanks to the combination of the Land Rover Off Road height and Easy Lift +70mm setting, for example, a total variation of about +125mm is obtainable.

The Special programs offer the ability to self – manage special or emergency situations:

The Self-Levelling program allows you to automatically level the vehicle in order to reach maximum comfort to sleep into the car or into a roof-placed tent. Easy Lift can compensate angles until 4/4,5° on a single axe or of equivalent value on the sum of both the axes, with a tolerance of 0,5° per axe.

The Wheel alignmentprogram performs an accurate wheel alignment of the vehicle; no more need to go to the dealer to lock and subsequently restore the suspensions, reducing time and costs of the intervention.

The Extra Low program enables to lower the vehicle down to the minimun limit allowed, without completely emptying the pneumatic system and/or without generation and recording of faults in the system board’s wheel speed sensor. It’s designed to facilitate the boarding and alighting of persons with reduced mobility or to facilitate the loading/unloading of luggage or parcels/materials from the vehicle, whether they are stored in the luggage door or on the roofrack.

Embedded ABS fault management:

In case of ABS sensor fault, car is programmed to lock uyser heights variations and lower each suspension on bump stops.

If this happen, with Easy Lift you’ll can continue to drive normally simply by raising the car with any its lift program higher than 40mm. You don’t need anything else. No special program are required in this case! Lift and drive!

Default Height customizable:

The default program reached by double-clicking the controller’s knob is “Neutral”. This default program can be customized following your own needs and preferences. Vehicles which feature big tires, for example, may need a greater default height compared to the Neutral one. Customers who own a more sporty vehicle may prefer a constant lowered setting, instead. Customization can be done through both the phone App (Settings page) and through the Controller.

Easy Lift is suitable on:

  • Land Rover Discovery 3/LR3 L319
  • Land Rover Discovery 4/LR4 L319
  • Range Rover Sport L320 Model Year 2004-2009
  • Range Rover Sport L320 Model Year 2010-2012
  • Range Rover L322 Model Year 2005-2012 (*)

(*) Before the purchase send us your VIN number for check the compatibility


EASY LIFT 4.0

  • Raise/Lower programs: 7
  • Factory heights (mm): -30, -20, -10, Neutral, +35, +55, +75
  • Programmable Heights: YES
    • Range: -35 to +75
  • Special programs: 3
    • Self-Levelling
    • Service
    • Extra Low

Price for D3/D4: € 410

Price for RRS: € 430 (ashtray adapter included)

Price for RR L322: € 430 (ecu holder included)

The smartphone App which completes the equipment of all Easy Lift versions and, simultaneously with the use of the car’s handsfree, allows to:

Customize the module (heights and default program)

to manage the module and view in real-time:

suspensions excursion

program or height activated

Mirroring the controller by displaying the program or height you are selecting while moving the knob

The App is customizable by choosing the vehicle model, the tyre type that you want to show (off road or road type) and it is available in English and Italiano. Get it now!

Advantages of risen heigths during Off Road performance:

  • Several more heights reachable, which can be changed according to the desires of the driver, depending on the route or the obstacles to face
  • Greater height from ground of the vehicle
  • Better attack, back and escape angles
  • Possibility to cover non asphalted roads to advanced speeds (more than 50 km/h)

Advantages of lowered heigths on asphalt

  • Reduced height of the vehicle from ground
  • Lower barycenter
  • Better aerodynamic coefficient
  • Reduced fuel burnups

Easy Lift User Manual

Video installation on Land Rover DISCOVERY 3/LR3

Video installation on Land Rover DISCOVERY 4/LR4

Video installation on RANGE ROVER SPORT MY05-09

Video installation on RANGE ROVER L322 up to MY2009

Additional information

Weight 1,5 kg
Dimensions 30 × 30 × 15 cm
